Small Type Modular 10nm3/H Purity 95% Industrial Nitrogen Generator
Key words：
Nitrogen Generators, Air Compressors, Oxygen and Other Gas Processing Equipment
Category：
Product Description
asy maintenance small type modular nitrogen generator 10Nm3/h,purity 95%
Modular Nitrogen Generator
PSA Modular nitrogen generator (pressure swing adsorption)technology,using air as raw materials,quality selection of adsorbent,and under certain pressure,the adsorption capacity of adsorbents for oxygen and nitrogen is different,though programmable program control pneumatic valve opening and closing to control the adsorber alternate cycle,pressure adsorption and vacuum stripping,complete separation of oxygen and nitrogen,get high purity
| Model | Specification | |
| TYN5-MK-95 | ||
| N2 capacity | Nm3/Hr | 10 |
| N2 purity | % | 95% |
| N2 outlet pressure | Mpa | 0.1~0.6 |
| Air inlet pressure | MPa | 0.7~0.8 |
| Air inlet temperature | ℃ | ≤38 |
| Dew point | ℃ | ≤-40 |
| Working condition | ||
| Air compressor flow | m³/Min | 0.5 |
| Max working pressure | MPa | 0.8 |
| Ambient temperature | ℃ | 40 |
| N2 outlet dia | DN | 15 |
| Air inlet dia | DN | 15 |
| Working cycle | S | 40-55 |
| Regeneration mode | Pressure swing analysis and alternate purging | |
| Voltage: | 220V/50Hz | |
| Pneumatic valve | mm | DN15*5 |
| Muffler | mm | customizing |
| Adsorbent | CMS260 | 1 batch |
| Controller | PLC | Siemens |
