All In One Psa Nitrogen Generation System For Food Bread Grain Chips Fresh Packing-Jiangsu Tongyue Gas System Co.,ltd.-nitrogen generators-air compressors

Bottled nitrogen does not undergo special treatment, has peculiar smell and contains much water. Nitrogen made by the nitrogen making machine does not have impurities or peculiar smell, the gas source is very dry and basically reaches the water-free low-oxygen state, and the equipment features small one-time investment, convenient operation, low running cost and quick response and can greatly prolong food preservation time. Foods are not always so well stored and preserved under higher nitrogen purity, and the best preservation effect can be achieved if ambient gas contains trace oxygen in the food preservation process.

Applicable Foods:

1. Beer, wine, fruit wine and edible oil should be used before pressure tanks and blown bottles are capped, which can remove oxygen and prevent non-carbonated beverages and edible oil from being oxidized, decayed or faded. If bottle corks are used, wooden plugs in bottles can be prevented from being mildewed, and nitrogen purity is ≥99%.

2. Puffed and fried foods: the foods can be prevented from being softened or deteriorated due to a small amount of water, and are well packaged and difficult to break during transportation.

3. Pastries, baked foods and egg pies: preservation time can be generally prolonged by 3-5 months. The foods can be prevented from being deformed or broken during transportation after nitrogen charging.

4. Milk powder and soybean milk powder: the phenomenon that the milk powder is agglomerated when extruded and stored for a long time can be prevented or reduced by using trace nitrogen.

5. Grains, nuts, fruits and vegetables: the harm of organisms such as pests can be prevented by charging nitrogen with the purity of 95%, 5% of oxygen can reduce the respiratory rate of the fruits, and the preservation effect is very obvious.

6. Candies and snack foods: they are mainly suitable to be packaged by airtight bags.

Technical features:

Only equipped with oil free or micro oil air compressor (see product is equipped with complete sets of equipment), nitrogen making mechanical and electrical source can boot the production of nitrogen, nitrogen purity can be adjusted by adjusting the nitrogen flow rate, the adjusting range is 95% ~ 99.99%.

2. A full set of automation equipment, and energy saving control, equipped with the inverter circuit to ensure a complete set of nitrogen making device in the economic operation and energy saving condition.

3. Nitrogen measurement instrument online continuous detection, real-time monitoring of nitrogen purity. The machine has compact structure, small size, easy to clean.

4. The unit adopts the optimization design, durable, investment recovery fast.

The main technical parameter list:

specifications	Nitrogen production Nm3/h	power (kW)	purity (%)	Air pressure Mpa	Producing nitrogen pressure Mpa	Overall dimensions mm
TY-3	3	0.5	99.5-99.99	0.8-1.0	0.1-0.65	570570950
TY-3	Note: for a pillow packaging machine inflatable, form a complete set of the displacement of air machine:≥0.4m³/min,≤The oil content:3ppm
TY-5	5	0.5	99.5-99.99	0.8-1.0	0.1-0.65	5705701200
TY-5	Note:for two inflatable pillow packaging machine,form a complete set of air compressor exhaust:≥0.6m³/min,≤The oil content:3ppm
TY-10	10	1	99.5-99.99	0.8-1.0	0.1-0.65	135012001650
TY-10	Note:for four pillow packaging machine or two vertical packaging machine inflatable,form a complete set of air compressor exhaust:≥0.9m³/min,≤The oil content:3ppm
TY-15	15	1	99.5-99.99	0.8-1.0	0.1-0.65	135012001650
TY-15	Note:for five pillow packaging machine or three vertical packaging machine inflatable,form a complete set of air compressor exhaust:≥1.25m³/min,≤The oil content:3ppm
TY-20	20	2	99.5-99.99	0.8-1.0	0.1-0.65	140012001800
TY-20	Note:for seven pillow packaging machine or five vertical packaging machine inflatable,form a complete set of air compressor exhaust:≥1.5m³/min,≤The oil content:3ppm
TY-30	30	2	99.5-99.99	0.8-1.0	0.1-0.65	140012001800
TY-30	Note:for ten pillow packaging machine or seven vertical packaging machine inflatable,form a complete set of air compressor exhaust:≥2m³/min, ≤The oil content:3ppm
TY-40 TY-50 TY-60 TY-70 TY-80 TY-100 TY-200
